The engine provides higher torque and overload recovery function, improves operating comfort and headroom, and can complete similar work with the same power at lower speed, lower noise and lower fuel consumption.
Engine: WEICHAI, National Ⅲ Emission Standard,74kw
Rated load: 1100Kg
Hydraulic system: Hydraulic pilot
Closed cab, spacious space, more convenient to drive.
With double handles for walking and operation control, it is easier to use.
Zero turning radius design, turning in place in narrow space, easy operation in warehouse, workshop and other restricted sites.
The quick-change device supports the minute-level replacement of dozens of accessories such as digging buckets
, forks and hammers, and the switching operation is seamless.
The reinforced frame is equipped with a high-torque engine, which can efficiently complete heavy-duty handling and stacking tasks in a narrow space.
Low grounding specific pressure design, with rubber track or anti-skid tire, it will not damage the foundation when working on sensitive ground such as lawn and floor tile.
Intuitive joystick + intelligent assistant system, the novice can operate skillfully in a short time, lowering the training threshold.
Load-sensitive hydraulic system distributes power on demand, and the fuel consumption of the same workload is more than 15% lower than that of traditional models.
Category | Specification |
Model | JC100 |
Operating Load | 1100 kg |
Max Speed | 9/18 km/h |
Rated Flux | 75 L/min |
High Flow Flux | 140 L/min |
Tire Model | 12-16.5 |
Rated Power | 74 kW |
Fuel Tank Capacity | 90 L |
Operating Weight w/ Bucket | 3550 kg |
Bucket Capacity | 0.55 m³ |
Overall Operating Height | 4070 mm |
Height to Bucket Hinge Pin | 3280 mm |
Height to Top of Cab | 2160 mm |
Height to Bottom of Level Bucket | 3140 mm |
Length without Bucket | 2880 mm |
Length with Bucket | 3580 mm |
Dumping Angle at Max Height | 40° |
Dumping Height | 2500 mm |
Dumping Reach | 700 mm |
Rollback Angle on Ground | 30° |
Rollback at Full Height | 104° |
Wheelbase | 1115 mm |
Ground Clearance | 205 mm |
Angle of Departure | 20° |
Front Turning Radius w/o Bucket | 1278 mm |
Front Turning Radius | 2144 mm |
Rear Turning Radius | 1857 mm |
Rear Overhang | 1082 mm |
Tread Width (standard tire) | 1500 mm |
Machine Width (standard tire) | 1880 mm |
Bucket Width (standard) | 1880 mm |
